Product Description

Rated Input Voltage 1 Phase 380V±10%, 50HZ/60/HZ
Rated Input Capacity 24.4KVA
Welding Current 100-500A
Welding Voltage 19-39V
Rated Duty Cycle 60%
Dimension (mm) 640 x 335 x 640
Weight 45Kg
Suitable Thickness of Steel Plate (mm) 3-35
Suitable Welding Wire (mm) 1.0/1.2/1.6
Cooling Method Force Fan-Cooling
Case Protection Class IP21
Executive Standard GB15579.1-2004
